Samebike XWP10

$899.00
Availability: In stock, ships within 2 business days

The classic model XWP10 city bike for transport and daily commute.

  • 36V 350W motor (560W peak)
  • 36V 10.4Ah lithium-ion battery
  • 27.5" x 17" 6061 AL alloy frame
  • 27.5" x 2.1" spoked tires
  • 0-5 levels power assist, Shimano 7-speed
  • Cruise control, pedal-assist, thumb throttle
$150 Off Code for Celebrate Daylight Saving:
DST2023

Bike Frame 6061 Aluminum frame


Display LCD display with phone holder
Transmission Shimano 7-speed gear shift system
Brake Mechanical disc brakes
Throttle Thumb throttle
Front Fork Alloy fork without suspension
Chain KMC chain
Tires 27.5*2.1" Tire
Rim Spoked wheel
Crank 170mm forged alloy
Mudboard N/A
Pedal Alloy pedal with reflectors
Battery Capacity 374.4Wh, 36V 10.4Ah
Battery Type Lithium-ion battery 18650 Ternary
Mileage Throttle only: 16-22 miles; Pedal assist: 32-45 miles
Motor Power 350w, 560w peak.
Motor Type Brushless Rear Hub Motor
Top Speed Legally 15.5 mph limited
Climbing Degree 14 Degrees
Gross Weight 45Lbs
Payload 265Lbs
Certificates CE UL KC FCC PSE ROHS

What's in the package?
1 x Electric Bicycle


1 x Battery
1 x Charger
1 x Toolset
1 x User Manual

User tools

Destination Processing time Shipping time
The United States 1 business days 3-12 business days
  • We provide free shipping to the contiguous United States;
  • FedEx/UPS will take the bike by the end of the next business day;
  • The tracking number will send to your email later, please add support@samebikeus.com to your email contacts;
  • Please contact us if you're convenient to pickup in California.
  • See more about shipping policy.
  • You have 15 days to test and experience the bike;
  • Please keep the original box and all items inside;
  • Please contact us immidiately if you have any question about the bike;
  • See more about return policy.

All bikes are covered by our all-inclusive warranty against all manufacturing defects for the original buyer/owner.

Part Type DLP
Frame Structure 3 Years
Front Fork Structure 3 Years
Hubs, headset, etc Structure 3 Years
Battery Electronics 12 Months
Motor Electronics 12 Months
Controller, headlight, etc. Electronics 12 Months
Brake pads Wearing parts 30 Days
Inner tubes Wearing parts 30 Days
Other accessories Accessories Shipping damage warranty

Size & Geometry

A -- Total Length 71"


B -- Handlebar Height 41"
C -- Wheelbase 42"
D -- Minimum Seat Height 30"
E -- Maximum Seat Height 38"
F -- Chain Stay Length 19"
G -- Standover Height 30"
H -- Top Tube Length 23"
I -- Wheel Diameter 27.5"
J -- Head Tube Length 6"
K -- Handlebar length 25"
L -- Minimum Seat Height to Floor 32"
