Samebike XWC05

Rated 4.7 out of 5
Based on 27 reviews
$1,199.00
$1,199.00 $1,299.00
Tax and shipping included.
Choose your color
Summer sale
How fast can it go? 27 mph after unlock[ i ].
What's the range? 28 - 55 miles per charge.
How much can it carry? Rider within 265lb.
All answered questions >
Check it What in the box Easy to put together
C05 Bike 85% pre-assembled
Battery One pair of keys
Battery Charger 2amp impulse charger
Pedal Set Mind the left and right
Seat Set Quick release seat tube
Full fender Rear fender assembled
Front wheel Spoked tire with reflector
Quick Release For front wheel
Toolkit Screws, wrenches, etc.

750W Brushless Geared Motor

The custom high rotating-speed brushless motor brings you strong power to cruising or commuting. Permanent magnet material coils enhanced efficiency and longevity.

Lithium-ion 48V 13Ah Battery

624Wh battery capacity with ZN2500MAH battery cells means you can travel effortlessly with throttle or pedal assist among 1,000+ times charge cycling.

Custom S830 LCD display

5-Levels Throttle and Pedal Assist, Cruise Control, 6km/h Walk Mode, Brake Cut-off.

Speedometer, Odometer, Battery level, Operate Indicator, Bike status, Adjustable Backlight, USB-A Port, Anti-misoperation Menu. Learn more >

Top speed up to 27 miles per hour for full throttle, pedal assist max 25mph
Over 50N⋅m max motor torque accelerate and climb with 1,000W peak power
Zhuoneng 18650-2500mAh cells Large capacity lithinum battery battery cells lifespan over 1,000 charge circles
5 - 7 hours full charge up to 28 - 55 miles per charge for your daily commute or outing campaign

EXPLORE WITH C05

Technical specifications Electronic system A reliable green-style transport
750W Motor brushless geared type
624Wh Battery 48V 13Ah lithium-ion
Impulse Charger 2Amp, overcharge protection
22Amp Controller Full power with motor
S830 LCD Display Most settings locked
Phone Charger 5V 1A USB-A
Headlamp With built-in horn
Thumb Throttle IP65 5V Throttle
Wiring Harness Waterproof connectors
Technical specifications Size & geometry Is this bike fit your body?
Handlebar height 39.6" Not ajustable
Seat height 30.7" - 35.4" Adjustable
Standover height 26.9" 27.8" - 39.5" inseam
Reach distance 20"
Bike weight Total 63.9 lb
Total length 68.1"
Wheelbsase 45.3"
Chainstay 19.7"
Wheel diameter 20"
Rack capacity 35lb
Top tube length 20.5"
Headtube length 4.7"
Seat tube Length 15"
Seatpost diameter 30.4mm
Handlebar width 24.4"
Technical specifications Other parts All are carefully selected, adjusted, and tested
Brake Levers Aluminum Alloy With motor cutoff
Brake Rotors Steel 160mm front and rear
Brake Pads Ceramic widened pads
Derailleur Shimano Tourney 7-Speed
Freewheel 7-Speed 14T - 28T
Shifter Shimano 7-Speed Thumb shifter
Fork Coil Suspension Adjustable and lockout
Frame 6061 Aluminum Alloy Mountain bike frame
Handlebar Aluminum Alloy Flat 31.8mm middle diameter
Crank Set 48T Square-taper Dual-sided chainring guard
Pedals 9"/16" Platform With reflector
Fenders Front & Rear Full coverage
Seatpost Aluminum Alloy 30.4mm diameter
Tires CST BFT 20" x 4"
Horn Electronic Integrated into headlamp
Rear Rack Bold Steel Can not carry people
Seatpost Aluminum Alloy 30.4mm diameter
Grips Durable PVC Ergonomic

Reviews and FAQs

What is the cost to replace the battery?

If the battery is found defective in 1-year after delivery, we will provide a new battery for free. Or please click here to buy a new battery.

Can I use the YY26 battery on this bike?

Yes, the battery for the YY26 bike is compatible with this bike.

What is the class of the bike?

It is a class 3 bike.

What is the size of the seatpost?

The original Seatpost is 30.4mm in diameter x 300mm in length.

Does this bike support cruise control?

Yes, you can start cruise by pressing the >down arrow button.

How do I change between the pedal assist and throttle?

All Samebike default support pedal assist + throttle mode. You can switch between electric/hybrid modes when riding by kicking the pedal or twisting the throttle at any time.

Is the pedal assist sensor cadence sensor or torque sensor?

The pedal assist sensor of this bike is cadence type. The faster pedaling will lead to a more powerful assist.

Do I have to leave the key in at all time to start and ride the bike?

Yes, the key can not be taken out when it's set to ON position.

Does the bike waterproof? Can I ride it in the rain?

The bike is IPX4 waterproof for outdoor use. You can ride it in the rain, but you should still wipe it to dry to avoid rusty.

Ask questions about this bike

average rating 4.7 out of 5
Based on 27 reviews
  • 5 Stars
    20 Reviews
  • 4 Stars
    6 Reviews
  • 3 Stars
    1 Review
  • 2 Stars
    0 Reviews
  • 1 Star
    0 Reviews
96% of reviewers would recommend this product to a friend
Customer photos and videos
27 Reviews
Reviewed by Spenser G., from United States
Verified Buyer
I recommend this product
Rated 5 out of 5
Review posted

SamEbike

This is a great bike! It's absolutely well made for this price. It's a lot of fun to ride even just around my house.

We bought two for our labor day campaign. One of them have little scratches on the frame but it's ok. Will recommend.

Loading...
Was this helpful?
Reviewed by Ken, from United States
Verified Buyer
I recommend this product
Rated 4 out of 5
Review posted

Off Road and Around Campus Cruiser

Great bike for the money ! You can't touch it anywhere for even close to this

price. Built well and rides great . The only thing I would change is I would go to belt drive and call it a day !! Still I would recommend this product .

Loading...
Was this helpful?
Reviewed by HEUSTONS L., from United States
Verified Buyer
I recommend this product
Rated 5 out of 5
Review posted

Seeing things, we would have never seen.

Easy to put together. Totally enjoy riding to the beach. We used the assist and rode 20 miles and used about 1/3 of the charge on the battery. We are very happy with our purchase. You still get the exercise, but when it comes to steep grades, the throttle helps. There's more to see when you're traveling at 20 mph.

Loading...
Was this helpful?
Reviewed by william t., from United States
Verified Buyer
I recommend this product
Rated 5 out of 5
Review posted

As a person over 70

As a person over 70 this bike fits my need perfectly and exceeded expectations. I am very pleased

Loading...
Was this helpful?
Reviewed by Rivendell, from United States
Verified Buyer
I recommend this product
Rated 5 out of 5
Review posted

OUTSTANDING QUALITY - FUN TO RIDE

Outstanding quality and utility in this ebike. I put 100 miles on it the first week and had no issues with it. The 750W motor is powerful enough to get me up steep hills with ease. Top speed is about 28 MPH, though I've gotten up to 38 MPH downhill. The battery lets me ride about 20 miles with the motor only, and about 50 miles using pedal assist (I live in a very hilly area). You will NOT be able to change some of the controller settings as these are set in the factory for the bike's optimum performance. The Operator's Manual is not very useful, so if you have questions, you will want to find help directly from the seller or from other sources on the internet, which is what I had to do. I use this bike on the street mostly, but I also have tried the trails and it performs exactly as intended after I adjusted the shock absorbers in the front wheel. The brakes are a bit squeaky, but perhaps they just need to get broken in... Overall, I really like this bike - its powerful and a lot of fun to ride.

Loading...
Was this helpful?

Which bike fits you best?

C05 Value for money $ 1,199.00
Black-silverBlack-red
5'2 to 6'3 Rider within 265 lbs
750W 1,000W Peak Powerful, Fast, Efficient 48V 13Ah Distant, Removeable Mechanical Brake Ceramic pads
20" x 4.0" Paved and unpaved ground, even wet or snow. S830 LCD 5-level pedal-assist, thumb throttle, speedometer, odometer 40Lb Cargo Steel rear rack, headlight, front & rear fender
YY26 Amazing power $ 1,399.00
Black
5'7 to 7'2 Rider within 265 lbs
750W 1,000W Peak Powerful, Fast, Efficient 48V 15Ah Distant, Removeable Mechanical Brake Ceramic-copper pads
26" x 4.0" Paved and unpaved ground, even wet or snow. S830 LCD 5-level pedal-assist, thumb throttle, speedometer, odometer No Rack Headlight, front & rear fender
M200 Plenty juice $ 1,799.00
WhiteBlack
5'3 to 6'11 Rider within 330 lbs
750W 1,000W Peak Powerful, Fast, Efficient 10Ah + 20Ah Triple Range, Convenient Mechanical Brake Ceramic-copper pads
20" x 4.0" Paved and unpaved ground, even wet or snow. M6T Color 5-level pedal-assist, thumb throttle, speedometer, odometer, wattmeter 55Lb Cargo Aluminum alloy rear rack, headlight, tail-light, front & rear fender
26A Expected comforts $ 999.00
Black
5'3 to 6'11 Rider within 265 lbs
500W 800W Peak Fast, Quite, Efficient 48V 12.5Ah Expected, Removeable Mechanical Brake Ceramic-copper widened pads
26" x 2.35" Paved and unpaved ground, better efficiency S830 LCD 5-level pedal-assist, thumb throttle, speedometer, odometer No Rack Headlight, front & rear fender
